Brand: APC Ups
Model: SRTG6KXLI
Color: Black
Max Configurable Power (Watts): 6.0kWatts / 6.0kVA
Rack Height: 4U
Nominal Output Voltage: 230V
Nominal Input Voltage: 230V
Output Connections:
2 IEC 60320 C13
1 IEC 60320 C19
Input Connections:
1 hard wire 3-wire (1P + N + E)
Mounting Mode: Rack-mounted with kit
Mounting Position: Horizontal
Battery type: Lead-acid battery
UPS Type: Double conversion online
Typical recharge time: 4 hour(s)
Nominal Battery Voltage: +/- 96 V
Expected Battery Life (years): 3-5
Battery Charger Power (Watts): 239 Watts
Input frequency: 40 - 70 Hz Auto-sensing
Input voltage range for main operations:
160...285 V full load
Input Current: 30 A
Max short time withstand current: 40 A
Output Frequency (sync to mains): 50/60 Hz +/- 4 Hz sync to mains
Waveform type: Sine wave
Bypass: Internal bypass (automatic and manual)
Efficiency: 93.5%
Alarm: Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm
Preinstalled device: Network management card 3 with environmental monitoring
Protection Class: IP20
Surge energy rating: 600Joules
Maximum Height: 17.5 cm
Maximum Width: 44 cm
Maximum Depth: 62 cm
Net Weight: 55.9 kg
