Brand: APC Ups
Model: SRTG20KXLI
Color: Black
Max Configurable Power (Watts): 20.0kWatts / 20.0kVA
Rack Height: 7U
Nominal Output Voltage: 230V
Nominal Input Voltage: 220...240 V
Output Connections:
Hard wire 5 wire (3P + N + E) 1
Hard wire 3-wire (1P + N + E) 1
IEC connector 3-wire (1P + N + E) 1
Input Connections:
1 hard wire 5 wire (3P + N + E)
Mounting Mode: Rack-mounted
Mounting Position: Horizontal
Battery type: Lead-acid battery
Typical recharge time: 4 hour(s)
Nominal Battery Voltage: +/- 192 V
Expected Battery Life (years): 3-5
Battery Charger Power (Watts): 2160 Watts
Input frequency: 40 - 70 Hz Auto-sensing
Input voltage range for main operations:
160...285 V full load
380 V 380...415 V
Input Current: 87 A
Switching current capacity: 125 A
Output Frequency (sync to mains): 50/60 Hz +/- 4 Hz Sync to mains
Waveform type: Sine wave
Bypass: Internal bypass (automatic and manual)
Efficiency: 94%
Alarm: Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm
Protection Class: IP20
Surge energy rating: 600Joules
Maximum Height: 30.6 cm
Maximum Width: 44.0 cm
Maximum Depth: 70.0 cm
Net Weight: 142.5 kg
